Your Professional Ceramic Quartz Silicon Parts Supplier


Founded in March 2017, with registered capital of 15 million yuan, Chinsor has a team master the core technology in this filed. Dedicated to supply of semiconductor flm physical deposition, chemical deposition and etching of precision parts, focusing on precision machining and parts surface treatment.




First 12345 Last

Why Choose Us

Quality Control

With modern production line, ERP guided production process and strict quality management system according to ISO9001.

Customization

Chinsor not noly provide parts for P5000, Centura 5200, Endura 5500, Emax, C1, but also supplies customized manufcature service for customers with samples and drawings.

Professional team

With an excellent design team of independent strong design and development capacity, our enterprise has been long dedicated to the research and development of safety and protective equipment and new products.

Foreign trade market

As a result of our high quality products and outstanding customer service, we have gained a global sales network reaching Southeast Asia, Middle East, America, and Europe.



Ceramic Quartz Silicon Parts Specifications



ltem

Test conditions

Unit

95% Alumina Ceramic

99% Alumina Ceramic

Bulk bensity

Room temperature

g/cm3

≥3.64

≥3.86

Helium leak rate( Tightness )



pa.m3/s

≤1x10-11

≤1x10-11

Flexural strength

Room temperature

MPa

336.1

368

The averace linear expansion coefficient

(20-500)℃

1/℃

7.27x10-6

7.15x10-6

(20-800)℃

7.73x10-6

7.71x10-6

Dielectric constant

1MHz 20℃



9.4

10.2

Volume resistivity

100℃

Ω.cm

5.2x1015

4.5x1015

300℃

5.6x1014

2.5x1013

500℃

4.8x1013

4.1x1011

Dielectric loss

20℃



2.4x10-4

1.9x10-4

DC Breakdown strength



KV/mm

42

36.9

Thermal stability

Room temperature-800℃



Pass

Pass

Chemical stability

1:9 HCI

mg/cm2

4.657

0..37

10% NaOH

0.075

0.04


Key Features
0200-00234 ISOLATOR BKM1 ENHANCED TXZ 200MM 2nd Source New

High purity and chemical resistance

Quartz in ceramic parts, especially in semiconductor applications, boasts exceptionally high purity levels (often ≥ 99.995%).



0200-20331 COVER RING 8

Excellent thermal stability and shock resistance

They can withstand extremely high temperatures, with a softening point of around 1700°C, and maintain performance during thermal cycling and rapid temperature changes.

0200-02420 DEP 环，200MM SIP TTN，带 BESC，陶瓷 第二源 新品

Low thermal expansion

The material exhibits a very low coefficient of thermal expansion, ensuring minimal dimensional changes even under significant temperature fluctuations.

0200-09315 HChuck，电调盖环，陶瓷，第二源新品

Good optical transmission

Fused quartz and related silica ceramics exhibit excellent transparency across a broad range of wavelengths, from the deep ultraviolet to the infrared.



Applications


Semiconductor Manufacturing

This is a significant application area, especially for high-purity quartz and silicon carbide (SiC) ceramics.

Optics and Optical Devices

Optical-grade quartz crystals are used to create specialized lenses, windows, and filters for various instruments, including lasers, microscopes, telescopes, and electronic sensors.

High-Temperature Environments

Both silica and silicon carbide ceramics are suitable for high-temperature applications due to their thermal stability and heat resistance.

Chemical and Fluidic Handling

Quartz is resistant to corrosion and chemicals, making it a valuable material for containers and components that come into contact with various chemicals and fluids.



Customized Process
0200-36105 CHAMBER INSERT 200MM TXZ CIP 2nd Source New


Demand Communication

Drawing Receipt: We receive your detailed design drawings or design requirements.


Requirement Confirmation: We discuss and confirm all design requirements.

0200-20331 COVER RING 8


Technical Evaluation

Feasibility Check: Our team evaluates the feasibility and production requirements.


Optimization: We provide suggestions for design optimization.

0020-22975 INSULATOR TIN 8INCH WAFER 2nd Source New


Sample Approval

Sample Production: We create initial samples and conduct performance tests.


Customer Confirmation: We send samples for your approval and adjust as needed.

0200-20285 PEDESTAL COVER UPPER 8


Production

Batch Production: We develop a production plan and begin batch production.


Quality Control: We ensure all products meet your quality standards.

0200-09315 HChuck, ESC Cover Ring, Ceramic, 2nd Source New


After-Sales Service

Logistics: We arrange delivery to ensure safe and timely arrival.


Support: We provide technical support and handle any defects.



Our Services


We support OEM and ODM.

We have a professional R&D team and technical support

We provide real-time logistics update information.

We support 24-hour online service.

We support T / T, L / C payment.

We have a professional QC team to check the quality before delivery.





Our Certificates





productcate-1-1



productcate-1-1



FAQ



Q: How can you get quotation?

A: Please kindly send me your drawing with technic requirement and demand quantity.If you don't have the drawing, please kindly courier samples to us. we will quote our best price in 24 hours.

Q: How can you get samples?

A: We can supply free samples if we have them in stock. If we havn't produce the products, we can supply some free samples after getting tool fee. Please take note that the courier fee should be at destination.

Q: What’s the lead-time for samples and batch orders?

A: It is 18days for supplying samples. It is around 25days for batch orders.

Q: Can I visit you?

A: Sure. If you're a volume buyer and would like to visit our in-house products and production line, please contact us to make an appointment.

Q: Why price is so low?

A: You are ordering from factory bottom price!

As one of the leading fragile material parts suppliers in China, we warmly welcome you to buy high-grade fragile material parts in stock here from our factory. All our products are with high quality and competitive price. Contact us for quotation.

0040 04745 Chamber Body Hdp cvd 2nd Source New,
